EK ECOLINE ART 1080 ASA ROMA
EK ECOLINE ART 1080 ASA ROMA
Stock:
In Stock
EK ECOLINE PVC ROOFING
PROFILE : ART 1080 ASA ROMA
What Is ASA Materials : Acrylic-Styrene-Acrylonitrile Copolymer (ASA) is a thermoplastic elastomer. This type of copolymer has excellent resistance to UV Irradiation, Heat, Moisture, and Stress cracking and probably has the best weathering resistance of all Acrylonitrile elastomer
PRODUCT FEATURES
PRODUCT SPECIFICATION
| Roof Curve Rib Height: | 30mm |
| Minimum Slope: | 7° and Above |
| Thickness Range From: | 2.00mm to 3.00mm |
| Effective Cover Width: | 940mm |
| Overall Cover Width: | 1080mm |
| Roofs Purlin Spacing: | 984mm |
ASA MATERIALS PROPERTIES
| Tensile Strength: | 35.0 – 50.5 MPa |
| Tensile Modulus: | 1,786 – 2,468 MPa |
| Elongation at Break: | 25 to 40% |
| Elongation at Yield: | ? 5.01% |
| Flexural Strength: | 38.6 – 78.6 MPa |
| Flexural Modulus: | 1,413 – 2,606 MPa |
| Glass Transition Temp: | ? 112 °C |
| Heat Deflection Temp: | (1.8MPa) |
