Minimum Slope: |
7° – 9° |
Thickness Range From: |
1.35mm to 2.20mm |
Effective Cover Width: |
762mm |
Overall Cover Width: |
825mm |
Roofs Purlin Spacing: |
900mm ~1200mm |
Roofs Lapping Add Additional Length: |
300mm |
Wall Cladding Purlin Spacing: |
1200mm ~1800mm |
THICKNESS & WEIGTH |
ROOFS |
WALLS |
||||||||
No |
Sheet Thickness |
Weight(kgs) |
Single Span |
End Span |
Internal Span |
Stiffened Overhang |
Single Span |
End Span |
Internal Span |
Stiffened Overhang |
1 |
1.35 mm |
2.848 kg |
900 mm |
900 mm |
1000 mm |
300 mm |
1200 mm |
1200 mm |
1400 mm |
200 mm |
2 |
1.50 mm |
3.165 kg |
1000 mm |
1000 mm |
1000 mm |
300 mm |
1200 mm |
1200 mm |
1400 mm |
200 mm |
3 |
1.65 mm |
3.481 kg |
1100 mm |
1100 mm |
1200 mm |
300 mm |
1200 mm |
1200 mm |
1400 mm |
200 mm |
4 |
1.80 mm |
3.798 kg |
1200 mm |
1200 mm |
1200mm |
300 mm |
1200 mm |
1200 mm |
1500 mm |
250 mm |
5 |
2.00 mm |
4.219 kg |
1200 mm |
1200 mm |
1200 mm |
300 mm |
1300 mm |
1300 mm |
1500 mm |
250 mm |
6 |
2.20 mm |
4.641 kg |
1200 mm |
1200 mm |
1200 mm |
350 mm |
1300 mm |
1300 mm |
1500 mm |
300 mm |
7 |
2.50 mm |
5.274 kg |
1300 mm |
1300 mm |
1300 mm |
350 mm |
1500 mm |
1500 mm |
1800 mm |
300 mm |
====================================================================================================================
