GI WELDED FENCE (ROLL TOP) | PAGAR BRC

GI (GALVANISED IRON) WELDED FENCE (ROLL TOP)

Safe, Rigid & High-Visibility Security welded Fence Supplier

Secure your site with High-Rigidity Welded Rolltop Fencing. Engineered with smooth edges for public safety and galvanized for Malaysian weather durability. Get competitive project rates today.

PRODUCT DESCRIPTION

Engineered for maximum safety, this Welded Rolltop Fence features unique rolled beam edges at the top and bottom to eliminate sharp points while significantly enhancing panel rigidity. Manufactured from high-tensile steel wire with superior corrosion resistance, it is the preferred specification for public infrastructure, schools, and residential perimeters.

PRODUCT DESCRIPTION

 Safety and Structural Durability
For contractors and developers delivering public-facing projects—such as schools, recreational parks, and residential precincts—conventional BRC fencing can pose risks. Exposed sharp edges increase safety liabilities, while long spans are prone to sagging over time. Professional buyers require a perimeter system that maintains clear visibility and an effective psychological anti-cut deterrent, while ensuring pedestrian safety and long-term structural stability under Malaysia’s high rainfall and humid conditions.

 Rolled Beam Geometry
The Welded Rolltop Fence resolves these issues through a rolled beam design at both the top and bottom edges. The triangular roll eliminates sharp protrusions, creating a safer, touch-friendly finish suitable for high-traffic areas and safety-regulated environments. Structurally, this rolled geometry functions as a horizontal stiffener, increasing tensile strength and significantly reducing panel deflection under impact and wind loads. Panels are protected with Hot Dipped Galvanized (HDG) finishing or Powder Coating for long-term resistance to corrosion and oxidation.

KEY TECHNICAL FEATURES

✓ Rolled Top & Bottom Beams: Significantly increases the panel’s lateral rigidity (stiffness) and eliminates sharp edges, making it the safest option for areas accessible to the public.

✓ High-Tensile Cold Drawn Steel: Provides exceptional impact resistance and maintains shape integrity better than standard mild steel alternatives.

✓ Open Mesh Design (150mm x 50mm): Offers high visibility for security monitoring (CCTV friendly) while allowing wind flow to reduce structural load during storms.

✓ Advanced Corrosion Protection: Treated with a high-grade galvanization process to withstand high humidity and coastal salinity (Tahan Karat), extending the lifecycle of the fence.





 APPLICATIONS & BENEFITS

• Educational Institutions (Schools/Universities): Perimeter definition without fortress aesthetics. Benefit: The smooth rolled edges prevent injury to students, satisfying strict safety audits.
• Public Infrastructure (Parks/Sports Complexes): High-traffic pedestrian management. Benefit: Extremely durable against low-to-medium impact (balls/equipment) while maintaining an open, welcoming visual appeal.
• Residential Developments (Gated Communities): Property delineation. Benefit: Offers a “Tahan Karat” solution that reduces maintenance costs.
• Commercial Facilities (Car Parks/Warehouses): Asset protection. Benefit: The rigid structure allows for easier installation of security systems and provides a clear line of sight for security guards.



SPECIFICATIONS

FENCE MODEL	HORIZONTAL MESH [mm]	VERTICAL MESH [mm]
KMJ-26RT	50mm [2”]	150mm [6”]
KMJ-28RT	50mm [2”]	200mm [8”]
KMJ-38RT	75mm [3”]	200mm [8”]

WIRE DIAMETER:

• 4mm +/-
• 5mm +/- SIRIM JKR Spec

SIZES

Height (ft)	Height (mm)	Width
3 ft	900 mm	2400 mm
4 ft	1200 mm
5 ft	1500 mm
6 ft	1800 mm
7 ft	2100 mm
8 ft	2400 mm



FENCE INSTALLATION :

FREQUENT ASKED QUESTION :

Q1

Question : What is the difference between FA Series (rolltop) and Roll Top BRC fencing? Answer : The FA Series usually refers to standard “Flat” or “Folded” BRC panels without the rolled edges, often used for temporary or basic borders. Roll Top BRC (often searched as Rolled Top Fence) features a triangular roll at the top and bottom for safety (no sharp edges) and extra rigidity. Roll Top is the preferred choice for schools and playgrounds (safety fencing), while FA Series is common for industrial zones.

Soalan : Apakah perbezaan antara Pagar BRC lipat atas siri FA dan “Roll Top”?

Jawapan : Siri FA biasanya merujuk kepada panel BRC “Rata” atau berlipat tanpa gulungan di hujung, sering digunakan untuk sempadan asas. Pagar BRC Roll Top mempunyai gulungan segi tiga di bahagian atas dan bawah untuk keselamatan (tiada bucu tajam) dan kekukuhan tambahan. Roll Top adalah pilihan utama untuk sekolah dan taman permainan, manakala siri FA biasa digunakan untuk kawasan industri.

Q2

Question : Can I perform a DIY installation for BRC fencing using wall plugs?

Answer : Yes. If installing on an existing concrete floor or drain, you can use base plates with wall plugs. However, for soil or grass areas, you must dig holes and use the concrete casting method (typically 300mm x 300mm footing) to ensure the hollow posts remain stable and do not lean over time.

Soalan : Bolehkah saya buat pemasangan DIY pagar BRC guna “wall plug”?

Jawapan : Ya. Jika dipasang di atas lantai konkrit atau longkang sedia ada, anda boleh gunakan tapak (base plate) dengan wallplug. Namun, untuk kawasan tanah atau rumput, anda mesti gali lubang dan guna kaedah tanam konkrit (biasanya tapak 300mm x 300mm) untuk memastikan tiang besi kekal kukuh dan tidak condong.

Q3

Question : Which is better: Hot Dipped Galvanized (HDG) or Powder Coated BRC?

Answer : For maximum rust resistance in Malaysia’s tropical weather, Hot Dipped Galvanized (HDG) is the best choice (lifespan 10-20 years). Powder Coated BRC is standard galvanized wire sprayed with colour (usually Green or Black) for aesthetics. Users often search for “Powder Coated Green BRC” for residential gardens, but HDG is recommended for high-humidity or coastal areas.

Soalan : Mana lebih baik: Galvanis Celup Panas (HDG) atau “Powder Coated”?

Jawapan : Untuk ketahanan karat maksimum dalam cuaca tropika Malaysia, Galvanis Celup Panas (HDG) adalah pilihan terbaik (jangka hayat 10-20 tahun). Powder Coated adalah wayar galvanis biasa yang disembur cat (biasanya Hijau atau Hitam) untuk kecantikan. Pengguna sering mencari “BRC Hijau” untuk taman rumah, tetapi HDG disyorkan untuk kawasan lembap atau berhampiran laut.

Q4

Question : What is the standard price per meter for BRC Roll Top Fencing in Malaysia?

Answer : Search queries for “Harga Pagar BRC” vary by height. Posts (Tiang): Sold separately.

Soalan : Berapakah harga standard semeter untuk Pagar BRC Roll Top di Malaysia?

Jawapan : Carian untuk “Harga Pagar BRC” berbeza mengikut ketinggian. Tiang: Dijual berasingan.
